Home > Solenoid > Permanent Magnet Solenoid

Permanent Magnet Solenoid

  • Since permanent magnets are assembled, after  energized, plunger can keep holding, even  power off, it's a power-save type solenoid.

  • De-energized holding force is in the range of 0.24-24kg, 12 basic types and 18 sizes for selection.

  • Pull force can be increased by the union outcome of inside magnet force and solenoid.
Please contact us for details

Tel: 0086-755-61561788
0086-13129556582
Fax: 0086-755-61561799

Email:sales@zonhen.com

MSN:douminger@hotmail.com

ID:douminger@hotmail.com

Skype ID:doumingerID:douminger
??? ID:zonhenID:zonhen
QQ:292089951ID:292089951

Product of Permanent Magnet Solenoid

single direction keep solenoid
Type
LXWXH

Picture(click big )

Power on time Keep force (kf) Force VS Stroke Power (W) Specification
ZHK-0112
3.7 x9 x 15.7

keep solenoid ZHK-0112

=1s 400 @ 1.67 keep solenoid
ZHK-0420
7.2 x11x 20.5

keep solenoid ZHK-0420

=1s 250 5gf@ 3mm 4.8 keep solenoid
ZHK-0421
9.4 x12x 21.4

keep solenoid ZHK-0421

=1s 200 20gf@ 4mm 6.0 keep solenoid
ZHK-0426
7.5 x11x 25.7

keep solenoid ZHK-0426

=0.2s 220 35gf@ 3mm 10.0 keep solenoid
ZHK-0520
13 x16x 20

keep solenoid ZHK-0520

=0.5s 220 8gf@ 5mm 3.6 keep solenoid
ZHK-0836
22 x26x 36.1

keep solenoid ZHK-0836

=1s 2200 850gf@ 3mm 38.5 keep solenoid
ZHK-1253
27 x30x 53

keep solenoid ZHK-1253

=0.5s 3700 450gf@10mm 10.0 keep solenoid
ZHK-1263
26 x30x 63

keep solenoid ZHK-1263

=0.5s 800 700gf@ 15mm 38.4 keep solenoid
Bi-direction keep solenoid:
Type
LXWXH

Picture(Click Big)

Power on time Keep force(kf) Force VS Stroke Power (W) Specification
ZHK-0221
?2 x 21

keep solenoid ZHK-0221

=0.2s 0.3 0.6gf@ 7.5mm 2.2 keep solenoid
ZHK-0521
13 x15x21

keep solenoid ZHK-0521

=0.1s 670 240gf@ 5mm 24.0 keep solenoid
ZHK-0720
18 x18x 20

keep solenoid ZHK-0720

=0.2s 600 150gf@ 5mm 24.0 keep solenoid
ZHK-0727
18 x18x 26.6

keep solenoid ZHK-0727

=0.2s 800 160gf@5mm 16.7 keep solenoid
ZHK-0735
14 x16x 35

keep solenoid ZHK-0735

=0.2s 600 150gf@ 5mm 36 keep solenoid
ZHK-1236
27 x30x 36

keep solenoid ZHK-1236

=0.2s 1400 150gf@ 9mm 24 keep solenoid
